Greywater recycling plant GWO 1.1-500

Compact Basic Garden Irrigation Kit     A ready-to-connect complete package that includes everything you need for rainwater irrigation in your garden. Except for the portable suction pump, everything is already professionally pre-installed. The suction pump is located outside the rainwater tanks and can also be used flexibly elsewhere. Do you have questions about the ideal tank size for your roof area and your individual consumption? Feel free to use our rainwater planner.       Scope of delivery     1,000-liter underground tank/cistern made of high-quality polyethylene     Plastic safety cover (walkable up to max. 200 kg)     Inlet flow regulator (installed)     Overflow siphon with animal protection (installed)     Water connection box with click-in fittings     20.4 m gutter grate with filter function     Floating intake filter including backflow preventer     10 m rainwater pressure hose     Self-priming jet centrifugal pump with hose connection     Labeling materials     15-year warranty on the underground tank in accordance with warranty terms How does garden irrigation work with the "basic" garden system?Rainwater flows from the roof through the gutter grate into the gutter and then via the downspout and the inlet surge arrester into the underground tank. (Multiple downspouts can also be connected.) The automatic submersible pressure pump located there is connected via a hose, which runs through a conduit, to the water dispenser. When the faucet on the water dispenser is opened, the pump starts automatically. Closing the faucet causes the submersible pressure pump to shut off on its own. You can install the water dispenser wherever is convenient for you. When the cistern is full, the rainwater drains off via the overflow siphon. The barrier integrated here, in turn, prevents small animals from entering. In winter, the pump must be disconnected from the power supply. Additionally, the water tap should remain open. You can find all further information in the download areaWho is the "basic" irrigation system suitable for? The complete set is suitable, on the one hand, for anyone who wants to keep the effort involved in installing their tank to a minimum. On the other hand, it is suitable for those who value the convenience of drawing water from a tap—for example, to fill a watering can. Is the "basic" garden system drive-over?  The underground tank is not drive-over in this form. However, upon request, all underground tanks with a capacity of 2,200 liters or more can be retrofitted with our vehicle-traffic-resistant kit. The resulting wheel load is 600 kg per wheel—which is sufficient for standard passenger cars and small vans. In this case, however, the cistern must have a soil cover of at least 60 centimeters.Where does the water from the overflow go when the tank is full? The excess rainwater can, on the one hand, be discharged into the sewer system. However, this incurs fees. Another disadvantage: The water does not return to the groundwater naturally. A good alternative is soakaway blocks, which help guide the rainwater through the soil back into the groundwater .Do I need a rainwater filter?The complete garden irrigation set generally does not require a rainwater filter. However, if you place particular importance on extra-clean water in your garden, you can install our fully biological Biovitor rainwater filter in all cisterns with a capacity of 2,200 liters or more. Our in-tank filter is suitable for 1,000-liter underground tanks. Important – Delivery Process: Our underground tanks are always delivered by a freight carrier. If accessories are shipped separately, this is done via a parcel service. The freight carrier will contact you 1–2 business days before the actual delivery date to clarify final details. For this, we need your phone number (ideally a cell phone number). We generally deliver cisterns or larger products by truck. The truck is unloaded at the curb. Please note, however, that suitable equipment (e.g., a mini-excavator) must be available on-site to transport the cistern to the installation location, or, depending on the size, 2–3 people must be available. Please refer to the “Technical Data” table for the specific cistern for the exact weight. In some cases, such as double or multi-tank systems, delivery may be made by semi-trailer truck. Therefore, please inform us immediately after placing your order if the desired delivery address is NOT accessible to a 40-ton truck. Otherwise, we cannot accommodate this during delivery!Please also note that no deliveries are made on Saturdays, Sundays, or holidays.

DetailsThe GRM 3.0 Rainwater Manager—with manual switching from rainwater to potable water supply—supplies water to all consumers. If there is no rainwater in the underground tank (e.g., due to a prolonged dry spell), the pump’s supply must be switched manually. Once the underground tank refills, the system can be manually switched back to rainwater supply. The pump is equipped with dry-run protection. The free outlet in accordance with DIN EN 1717 prevents rainwater from mixing with water from the water utility. Scope of deliveryRainwater Manager GRM 3.0 (manual)Floating intake filter incl. 10m hose"Rainwater" labeling setConnection setClamp

DetailsBasement tank made of high-quality plastic with a cover for rainwater harvesting. Seamlessly manufactured using a rotational molding process and reinforced with a 5-layer steel profile. Technical Specifications Material: PolyethyleneColor: black Weight: 255 kg Useful volume: 4,000 liters Length: 2,430 mm Width: 1,000 mm Height: 1,875 mmWith Biovitor DN200

GreenLife underground drinking water tanks are suitable for storing drinking waterDom-in-Dom safety lock*—for high hygiene standards—Tank made of drinking-water-safe, environmentally friendly polyethyleneInlet via screw connection (included)*The 1,000-liter drinking water underground tank does not have a dome-in-dome safety lock!

DetailsDevice for refilling the cistern with drinking water. When the water level in the rainwater cistern, the basement tank, or the service water tank of a graywater recycling system drops, a solenoid valve is opened via the float switch and drinking water is added. Technical Data Height: approx. 875 mmDiameter: approx. 110 mmSolenoid valve with connection cable and plug Connection: 1" thread Float switch with 20 m cable Adapter plug and weight
