Pumps for Rainwater Harvesting – Efficient Water Supply for Sustainable Irrigation

Floating suction filter

DetailsWater extraction in clean areasSinkable and suspended solids are not drawn in5 m 1" suction hose with clampsBrass check valveSuction filter

Self-priming jet centrifugal pump

Specifications (Compact)Max. delivery rate/flow rate: 50 l/min Max. head: 38 m / Pressure: 3.8 barConnection sizes: 1" (inch) male (external thread)Power cord length: 1.2 m Suitable for: Rainwater harvesting, clean water use Max. suction depth: 8 meters Self-priming, reliable pump, ideal for garden irrigation The Jet centrifugal pump can be used to pump clear water, for example for watering a garden or green space. It is self-priming and pumps clear water or rainwater from a tank (cistern). A control unit in the form of an automatic switch can be mounted on the pump, ensuring automatic on/off operation and dry-run protection when the cistern is empty. This allows the Jet pump to also be used as an affordable domestic water supply system—due to its single impeller, it has a higher sound pressure level than, for example, the AMIGA MH800.  As a garden pump, it is perfectly suited for rainwater harvesting systems. Operation / Performance: The Jet centrifugal pump has a maximum flow rate of 50 liters per minute, a maximum head of 38 meters, and a pressure of 3.8 bar. The power consumption is 0.81 kW / 3.7 A. The jet centrifugal pump features an on/off switch and a carrying handle. The maximum suction line length is 15 meters; the maximum suction head between the cistern floor and the pump’s suction connection should not exceed 8 meters. If the suction line exceeds these values, it is recommended to use a submersible pressure pump (e.g., GAP X120, GUP46). All specified values are maximum values, which may be lower when used in combination. Quality: The solid construction of this pump, made from materials such as stainless steel and durably coated cast iron, ensures durability and reliable performance. Strict controls and careful testing guarantee excellent quality. With protection class IP 44, the pump is protected against dust and splashing water. Conclusion: The Jet centrifugal pump is the ideal choice for anyone looking for an efficient, self-priming, and affordable pump to ensure their (rain)water supply in the garden. Additional Features & Notes: The Jet centrifugal pump can be secured to a solid surface such as wood or concrete using its sturdy base. The pump should be operated in a dry location. The pump weighs 7.2 kilograms.  Maintenance and installation instructions: Please follow the installation and operating instructions. If there is a risk of frost, drain the pump and store it in a frost-proof location. Do you have questions about this pump or other rainwater harvesting products? Our customer service team is available to provide expert assistance: 0385 77 337 72 (weekdays 8 a.m.–4 p.m.).   Our service promise: In the event of a repair, we will send you a free return label for shipping via DHL to our factory—during the 24-month statutory warranty period. Scope of delivery:  Jet centrifugal pump complete with connection cable and Schuko plug wiring (cable length 1.2 meters)HandleAccessories for the suction side: Brass fitting (hose nozzle to 1" union nut), clamp for 29–31 mmAccessories for the discharge side: Quick-connect coupling to 1" female thread, quick-connect coupling to 3/4" hose nozzle, quick-connect coupling to 1/2" hose nozzle Operating instructions    Delivery of this product via parcel service Looking for a different pump...? AMIGA MH800 4M Pump … a dry-mounted pressure pump for domestic applications that reliably and quietly delivers clean water at a maximum pressure of 3.5 bar. GUP 46 Clear Water Pressure Pump … a particularly durable pump that operates as a submersible pressure pump underwater in a cistern or tank and is automatically controlled in the house via an automatic switch (pressure switch, e.g., installed in the house).  GAP X 80 Automatic Submersible Pressure Pump … an automatic submersible pressure pump designed for the reliable extraction of clear water from rain barrels, rainwater systems, flat tanks, and cisterns for the irrigation of gardens and green spaces. GAP X 120 Automatic Submersible Pressure Pump … a modern pump that operates as a submersible pressure pump underwater in a cistern or tank and features dry-run protection via a switch control unit integrated directly into the pump.  TPV 200 wastewater pump ... a particularly durable, heavy-duty pump capable of pumping wastewater from a tank, cistern, pit, or basement.

Amiga MH1100 4M domestic water pump - quiet pressure pump for rainwater and clear water

Brief specifications Max. delivery rate/flow rate: 90 l/min Max. head: 52 m (5.2 bar) Connection: 1" female thread (FT) Power cord length: 1.2 m Suitable for: Rainwater harvesting, clean water use Max. suction depth: 8 meters Reliable pump for rainwater and clear water use The Amiga MH1100 4M is a powerful and exceptionally quiet pressure pump designed to reliably supply rainwater and clear water for home and garden use. It is ideal for use in building services, such as rainwater harvesting systems or for domestic water supply. When combined with an automatic switch (accessories: automatic switch 54, 87, or 65), the pump is ideal as a domestic waterworks system for automated water supply, for example, for medium-sized residential units. It is also optimally suited for rainwater harvesting systems as well as for pressure boosting and household water supply. Thanks to self-priming technology, water can be reliably pumped even from lower-lying sources such as cisterns or tanks. This makes the pump ideal for a convenient and efficient water supply in everyday life. Quality & Performance This pump (including impellers and shaft) is made of stainless steel and coated cast iron and is designed for long-lasting and reliable use. Quality is ensured through regular inspections and careful testing. Thanks to its four integrated impellers (=stages), this centrifugal pump operates very quietly and smoothly. It has a maximum flow rate of 90 liters per minute, a maximum head of 52 meters, and builds up a pressure of up to 5.2 bar. The power consumption is 0.75 kW. Maintenance and Installation Instructions The pump should be installed in a dry location. For wall mounting, we recommend the wall bracket for the Amiga MH800/Amiga MH 1100 4M pumps. If there is a risk of frost, drain the pump and store it in a frost-proof location. Please follow the installation and operating instructions. Our Service Promise In the event of a repair, we guarantee a pickup service within Germany during the 24-month statutory warranty period. Looking for a different pump...?AMIGA MH800 4M Pump ...a pump of the same quality with slightly lower performance at a lower priceJet Centrifugal Pump …a pump with a handle that, as a single-stage centrifugal pump, can be used in a variety of ways for garden irrigation. GUP 46 Clear Water Pressure Pump … a particularly durable pump that operates as a submersible pressure pump underwater in a cistern or tank and is automatically controlled in the house via an automatic switch (pressure switch, e.g., installed in the house).  GAP X 80 Automatic Submersible Pressure Pump … an automatic submersible pressure pump designed for the reliable extraction of clear water from rain barrels, rainwater systems, flat tanks, and cisterns for the irrigation of gardens and green spaces. GAP X 120 Automatic Submersible Pressure Pump … a modern pump that operates as a submersible pressure pump underwater in a cistern or tank and features dry-run protection via an automatic switch integrated directly into the pump.  TPV 200 wastewater pump ... a particularly durable, heavy-duty pump capable of pumping wastewater from a tank, cistern, pit, or basement.

Amiga MH800 4M domestic water pump - quiet pressure pump for rainwater and clear water

Brief Specifications Max. delivery rate/flow rate: 60 l/min Max. head: 35 m (3.5 bar) Connection: 1" female thread (FT) Power cord length: 1.2 m Suitable for: Rainwater harvesting, clear water use Max. suction depth: 8 meters Reliable pressure pump for domestic water supply with rainwater and clear water The Amiga MH800 4M is a powerful and exceptionally quiet pressure pump for the reliable supply of rainwater and clear water in the home and garden. It is ideally suited for rainwater harvesting systems and domestic water supply. When combined with an automatic switch (accessories: automatic switch 54, 87, or 65), the pump is ideal as a domestic waterworks system for automated water supply, for example, for small to medium-sized residential units. It is also optimally suited for rainwater harvesting systems as well as for boosting water pressure in the home. Thanks to its self-priming technology, water can be reliably pumped even from lower-lying sources such as cisterns or tanks. This makes the pump ideal for a convenient and efficient water supply in everyday life. Quality & Performance This pump (including impellers and shaft) is made of stainless steel and coated cast iron and is designed for long-lasting and reliable use. Quality is ensured through regular inspections and careful testing. Thanks to its four integrated impellers, this centrifugal pump operates very quietly and smoothly. It has a maximum flow rate of 60 liters per minute, a maximum head of 35 meters, and builds up a pressure of up to 3.5 bar. The pump is suitable for reliable use indoors and in sheltered outdoor areas. Maintenance and Installation Instructions The pump should be installed in a dry location. For wall mounting, we recommend the wall bracket for the Amiga MH800/Amiga MH1100 4M pumps. If there is a risk of frost, drain the pump and store it in a frost-free location. Please follow the installation and operating instructions. Our Service Promise In the event of a repair, we guarantee a pickup service within Germany during the 24-month statutory warranty period. Looking for a suitable alternative? AMIGA MH1100 4M Pump – same design, but higher performance for larger households and greater delivery pressure Jet centrifugal pump – versatile garden pump with handle GUP 46 Clear Water Pressure Pump – submersible pressure pump for cisterns or tanks with an external automatic switch. GAP X 80 Automatic Submersible Pressure Pump – for rain barrels, flat tanks, and cisterns. GAP X 120 automatic submersible pressure pump – with integrated automatic switch and dry-run protection. TPV 200 wastewater pump – robust pump for pumping out wastewater.

Automatic gearshift 54

With pressure gauge Pump control switch 54, including pressure gauge and dry-run protection. Fully wired. Technical data Max. current: 16 (8) A Start-up pressure: 1.5 bar Max. permissible pressure: 10 bar Max. fluid temperature: 60°C Connections: 1-inch male thread

Automatic gearshift 65

With pressure gauge Pump control switch 65, including pressure gauge and dry-run protection. Fully wired. Technical data Standby power consumption: <0.25 W Max. current: 12 A Adjustment range for switch-on pressure: 1–3.5 bar Maximum permissible pressure: 10 bar Fluid temperature: 5° - 35°C Connections: 1-inch male thread

Automatic gearshift 87

With pressure gauge Pump control switch 87, including pressure gauge and dry-run protection. Fully wired. Technical data Max. current: 16 (8) A Switching pressure range: 1.5 - 3.5 bar Max. permissible pressure: 10 bar Max. fluid temperature: 60°C Connections: 1-inch male thread

Automatic submersible pressure pump GAP X120 with lateral suction and integrated automatic switch

Specifications at a glance:Max. Delivery rate/flow rate: 100 l/min (6.0 m³/h)Max. Head: 45 m / Pressure: 4.5 barConnection sizes: 1" (inch) F (female thread)Power cord length: 15 mSuitable for: Rainwater harvesting, via side intake: floating extraction of clean water from below the water surfaceMax. immersion depth: 12 mHigh-performance submersible pressure pump for versatile applications Our automatic GreenLife GAP X120 submersible pressure pump is a modern, powerful, and reliable submersible pressure pump. It handles large flow rates with ease and is suitable for a wide range of applications, such as water supply and drainage tasks in clear water. The pump automatically regulates the water flow based on the user’s water demand. Examples of applications:  Extraction of rainwater from rainwater systems, tanks, and cisternsUse of clear water inside or outside a buildingIrrigation of a lawn or gardenOperation of sprinklers or sprayers (on average, three sprinklers can be operated simultaneously)Draining or pumping water, for example from poolsDomestic water supply Operation / Performance: The pump is fully submersible and is immersed in the water. The maximum immersion depth is 12 meters. The pump automatically controls water delivery when the line to the consumer is open (faucet open). When the consumer is closed, the pump switches to standby mode. The pump is then in start/stop mode and maintains pressure in the line. When the consumer is opened again, the pump restarts and delivers water.  The GAP X120 has a maximum flow rate of 100 liters per minute and a maximum head of 45 meters. This extremely high-pressure pump, with a maximum of 4.5 bar, enables effortless and effective irrigation. The power consumption (P1) is 1.15 kW. A built-in thermal motor protection prevents overload and ensures automatic restart after cooling down. Optionally, a pump base with side suction can be mounted for floating intake. This allows clean water to be drawn from below the water surface, not from the bottom. Quality: The use of stainless steel and high-quality plastic ensures a long service life. An integrated dry-run protection shuts off the pump in case of water shortage. A practical handle makes transporting the pump a breeze. With an IP 68 protection rating, the pump is dust- and waterproof. Conclusion: With the GAP X120 submersible pressure pump, you are purchasing a modern, automatic pump that switches on and off automatically according to water demand, features dry-run protection and thermal motor protection, and is suitable for both side and floating suction. Additional Features & Notes: Do not pump saltwater, wastewater, corrosive, highly flammable, or explosive substances (e.g., gasoline, kerosene, nitro thinner), oils such as heating oil and vegetable oils, or food! The water temperature must not exceed 35°C. An integrated, easy-to-clean stainless steel suction filter provides optimal protection against debris.Please note that (as described in the installation and operating instructions) this is a clear water pump that must only pump clean water—ideally pre-filtered with the Biovitor—to remain fully functional.  You also have the option of using the pump base if the pump is placed on a surface rather than suspended (see installation instructions). Maintenance and Installation Instructions: If there is a risk of frost, drain the pump and store it in a frost-free location. Please follow the installation and operating instructions. Do you have questions about this pump or other rainwater harvesting products? Our customer service team is here to provide expert assistance: 0385 77 337 72 (weekdays 8 a.m.–4 p.m.). Our service promise: In the event of a repair, we will send you a free return label for shipping via DHL to our factory—during the 24-month statutory warranty period. Scope of delivery:  GAP X120 submersible pump complete with connection cable and Schuko plug (cable length 15 meters)Additional pump base with 1-inch external thread on the side90° elbow (1-inch with female thread)Stainless steel suction filter (1-inch male thread; replace the pump base to install the suction filter)Double nipple (1-inch, for screwing in the hose connection nozzle)2 hose connection fittings, each 1 inch & ¾ inch with union nut (incl. 2 gaskets)Clamp (31–34 mm)Rope (for suspending the pump and for easy removal from the cistern)Installation and operating instructions Delivery of this product via parcel service Looking for a different pump...?AMIGA MH1100 4M Pump ... a dry-mounted pressure pump for domestic use that reliably and quietly delivers clean water at a maximum pressure of 5.2 bar?Jet centrifugal pump … a pump with a handle that, as a single-stage centrifugal pump, can be used in a variety of ways for garden irrigation. GUP 46 Clear Water Pressure Pump … a particularly durable pump that operates as a submersible pressure pump underwater in a cistern or tank and is automatically controlled in the house via an automatic switch (pressure switch, e.g., installed in the house). GAP X 80 Automatic Submersible Pressure Pump … an automatic submersible pressure pump designed for the reliable extraction of clear water from rain barrels, rainwater systems, flat tanks, and cisterns for the irrigation of gardens and green spaces. TPV 200 wastewater pump ... a particularly durable, heavy-duty pump capable of pumping wastewater from a tank/cistern, a pit, or a basement.

Clear water pressure pump DAB Divertron X 650

Specifications at a glance:Max. Delivery rate/flow rate: 100 l/min (6 m³/h)Max. Delivery head: 30 m / Pressure: 3.0 barConnection sizes: 1" (inch) F (female thread)Power cord length: 15 mSuitable for: Rainwater harvesting, clear water useMax. immersion depth: 12 mDAB Divertron X 650 electronic multistage submersible pressure pump The DAB Divertron X 650 pump is designed for pumping clean water, e.g., rainwater, for gardening and irrigation. As a multistage submersible pump with integrated electronics for automatic on/off switching, it can be installed in collection tanks, wells, tanks, or cisterns with a maximum submersion depth of 12 meters.  Examples of applications:  Extraction of rainwater from rainwater systems, tanks, and cisternsUse of clear water inside or outside a buildingIrrigation of a green area or gardenOperation of sprinklers or sprayers (on average, three sprinklers can be operated simultaneously)Draining or pumping water, for example from poolsDomestic water supply How it works / Performance: Depending on the water volume, the integrated control system switches the pump on and off fully automatically: For example, when you turn on a faucet, the pump starts automatically and switches off again after the faucet is turned off. An integrated dry-run protection ensures that the pump is not damaged—it switches itself off automatically when there is a lack of water. An automatic reset returns the pump to operating mode after a malfunction. The pump features an integrated check valve, an integrated start-up capacitor, and thermal protection against motor overheating. A pressure switch and flow sensor are also integrated. The DAB Divertron X 650 has a maximum flow rate of 100 liters per minute, a maximum head of 30 meters, and builds up a pressure of up to 3.0 bar. The power consumption (P1) is 0.63 kW.  Quality: The DAB Divertron X 650 pump body and impellers are made of technopolymer (a high-quality, durable plastic) to resist corrosion and oxidation. The motor shaft is made of stainless steel (AISI 416 + AISI 304). The pump is characterized by high operational safety, easy installation, and high reliability. It is suitable for continuous operation and is quiet since it is installed underwater. With an IP 68 protection rating, the pump is dust- and watertight. Conclusion: The DAB Divertron X 650 is a high-quality electronic, multistage submersible pressure pump with an integrated control unit. It is ideal for use with rainwater/clear water in the home and garden. Additional Features & Notes: The pumped medium must be clean, free of solid or abrasive substances, non-viscous, non-corrosive, non-crystalline, and chemically neutral. Quick access to the capacitor is possible without disassembling the pump. We recommend a small expansion tank (installed in the pressure line) as an option in case of leaks or low water consumption. The pump can be installed in a fixed or movable vertical position. The pump weighs 9.5 kilograms.Please note that (as described in the installation and operating instructions) this is a clear water pump that must only be used to transport clean water—ideally pre-filtered with the Biovitor—to ensure long-term functionality. Maintenance and Installation Instructions: If there is a risk of frost, drain the pump and store it in a frost-free location. Please follow the installation and operating instructions. Do you have questions about this pump or other rainwater harvesting products? You can get expert assistance from our customer service: 0385 77 337 72 (weekdays 8 a.m.–4 p.m.). Our service promise:In the event of a repair, we will send you a free return label for shipping via DHL to our factory—during the 24-month statutory warranty period. Scope of delivery:  Clear water pressure pump complete with connection cable and Schuko plug wiring (cable length 15 meters) with 1" (inch) side suction port for floating intake, built-in check valve90° elbow (1 inch with female thread)Stainless steel suction filter (1-inch external thread)1 hose connection fitting, 1 inch1 clamp for 31–34 mm1 10 mm anchor, 1 hookRope for suspending the pump for easy removal from the cisternQuick start guide (detailed operating instructions here), safety instructionsThis product is delivered via parcel service Looking for a different pump...?AMIGA MH1100 4M Pump ... a dry-mounted pressure pump for domestic use that reliably and quietly delivers clear water at a maximum pressure of 5.2 bar?Jet centrifugal pump … a pump with a handle that, as a single-stage centrifugal pump, can be used in a variety of ways for garden irrigation. GUP 46 Clear Water Pressure Pump … a particularly durable pump that operates as a submersible pressure pump underwater in a cistern or tank and is automatically controlled in the house via an automatic switch (pressure switch, e.g., installed in the house). GAP X 80 Automatic Submersible Pressure Pump … an automatic submersible pressure pump designed for the reliable extraction of clear water from rain barrels, rainwater systems, flat tanks, and cisterns for the irrigation of gardens and green spaces. TPV 200 wastewater pump ... a particularly durable, heavy-duty pump capable of pumping wastewater from a tank/cistern, a pit, or a basement.

Clear water pressure pump GUP 46

Specifications at a glance:Max. Delivery rate/flow rate: 75 l/min (4.5 m³/h)Max. Head: 44 m / Pressure: 4.4 barConnection sizes: Suction line 1 ¼" (inches) IG (internal thread), discharge line 1 ¼" (inches) external threadPower cord length: 15 mSuitable for: Rainwater harvesting, clear water useMax. immersion depth: 20 mHigh-quality and durable submersible pressure pump made of stainless steel, e.g., for building servicesThe high-quality, durable, and powerful GUP 46 submersible pressure pump delivers clear water in a stainless steel housing for home and garden irrigation. It can be installed in a clean water source, such as a well, reservoir, collection tank, or rainwater tank/cistern. As a multistage submersible pressure pump, it is primarily used in building services. A float switch acts as dry-run protection. Operation / Performance: The pump is installed in the water and draws water through a 1 ¼-inch connection located on the lower side of the pump. A floating suction filter is typically connected to this. Automatic operation of the pump is achieved via an automatic switch located in the discharge line (e.g., installed inside the house). The pump is characterized by its quiet operation and is virtually silent underwater. The GUP 46 has a maximum flow rate of 75 liters per minute, a maximum head of 44 meters, and builds up a pressure of up to 4.4 bar. The power consumption (P1) is 0.85 kW.  Quality: This pump delivers water using four stainless steel impellers on a stainless steel shaft within a stainless steel housing—all water-contacting components are made of stainless materials. Protection class IP 68 ensures the pump is protected against dust and continuous submersion in water. A float switch acts as dry-run protection. Conclusion: The GUP 46 stainless steel submersible pressure pump is durable and perfectly suited for permanent installation, for example in a rainwater tank used to supply your home. All components that come into contact with water are made of non-corrosive materials (stainless steel). Additional features & notes: Do not pump saltwater, wastewater, corrosive, highly flammable, or explosive substances (e.g., gasoline, kerosene, nitro thinner), or oils such as heating oil and vegetable oils! The water temperature must not exceed 40°C. In case of overload, the pump is shut off by the built-in thermal protection switch. After cooling down, the motor restarts automatically. The pump weighs 16.7 kg. The EAN number is 4400008111436.Please note that (as described in the installation and operating instructions) this is a clear water pump that must only be used to transport clean water—ideally pre-filtered with the Biovitor—to ensure long-term functionality. Maintenance and Installation Instructions: The pump is maintenance-free and must be installed in a frost-proof location. When used in above-ground tanks, it must be drained in winter if there is a risk of frost and stored in a frost-proof location. Please follow the installation and operating instructions. Do you have questions about this pump or other rainwater harvesting products? Our customer service team is available to provide expert assistance: 0385 77 337 72 (weekdays 8 a.m.–4 p.m.).  Our service promise: In the event of a repair, we will send you a free return label for shipping via DHL to our factory—during the 24-month statutory warranty period. Scope of delivery:   GUP 46 submersible pressure pump with side suction port 1 ¼ inch, with float switch for dry-run protection, with connection cable and Schuko plug (cable length 15 m) Installation and operating instructionsDelivery of this product via parcel serviceLooking for a different pump...?AMIGA MH1100 4M pump ... a dry-mounted pressure pump for domestic use that reliably and quietly delivers clear water at a maximum pressure of 5.2 bar?Jet centrifugal pump … a pump with a handle that, as a single-stage centrifugal pump, can be used in a variety of ways for garden irrigation. GAP X 80 Automatic Submersible Pressure Pump … an automatic submersible pressure pump designed for the reliable extraction of clear water from rain barrels, rainwater systems, flat tanks, and cisterns for the irrigation of gardens and green spaces.GAP X 120 Automatic Submersible Pressure Pump … a modern submersible pressure pump that operates underwater in a cistern or tank and features dry-run protection via an automatic switch integrated into the pump. TPV 200 wastewater pump ... a particularly durable, heavy-duty pump capable of pumping wastewater from a tank, cistern, pit, or basement.

Connection set for GRM

Reinforced hose with a 1-inch ball valve, reinforced hose with a 3/4-inch ball valve

Dirt water pump TPV 200

Specifications (summary):Max. Delivery rate/flow rate: 140 l/min (8.4 m³/h)Max. Delivery head: 7 m / Pressure: 0.7 barConnection sizes: 1 ¼" (inches) F (female thread)Power cord length: 10 mSuitable for: Wastewater with particle sizes up to 19 mmMax. immersion depth: 8 mReliable TPV 200 wastewater pump This submersible pump is a simple, particularly durable, and robust pump, which is primarily used for pumping contaminated water and wastewater. The TPV 200 is the version without a float switch—it does not have dry-run protection.  Applications:mobile drainagedomestic drainagerainwater drainagedrainage of flooded basementscirculating pond water or oxygenation for fish pondsWater features and waterfallsWastewater drainage from shafts, pits, tanks, and cisternsSolid particles in the wastewater should not be larger than 19 millimeters.  Functionality / Performance: This pump conveys wastewater using vortex impellers. The motor is continuously cooled by the medium being transported, which significantly reduces the motor’s operating temperature. This pump model features an integrated thermal protection switch: The pump stops as soon as an overload occurs—the motor automatically restarts after the pump has cooled down. The TPV 200 has a maximum flow rate of 140 liters per minute, a maximum head of 7 meters, and builds up a pressure of up to 0.7 bar. The power consumption (P1) is 0.31 kW.  Quality: The TPV-200 series is made of high-quality plastic. The bearings and mechanical seal are designed for a long service life and guarantee continuous operation. The pump is very easy to clean and maintain thanks to its simple disassembly. The pump has a low weight of 4.9 kg. With an IP 68 protection rating, the pump is dust- and waterproof. Conclusion: The reliable and durable TPV 200 transfer pump is suitable for transporting contaminated water and wastewater containing solids with a particle size of up to 19 millimeters. Additional features & notes: Larger particles—with a particle size exceeding 19 millimeters—will clog the suction strainer: Failure to observe this will reduce the pump’s service life or cause it to malfunction. The pump must not be used for seawater, flammable, corrosive, explosive, or hazardous liquids. The maximum temperature of the medium being pumped must not exceed 40°C. Ensure that the pump does not run dry.Maintenance and Installation Instructions: The pump is maintenance-free and must be installed in a frost-proof location. When used in above-ground tanks, it must be drained in winter and stored in a frost-proof location. Please follow the installation and operating instructions. Do you have questions about this pump or other rainwater harvesting products? Our customer service team is available to provide expert assistance: 0385 77 337 72 (weekdays 8 a.m.–4 p.m.). Our service promise: Guaranteed pickup service within Germany in the event of repairs during the 24-month statutory warranty period. Scope of delivery:   TPV 200 submersible pump with connection cable and Schuko plug wiring (cable length 10 m) Operating instructionsThis product is delivered via parcel service. Looking for a different pump...? TPV 200A wastewater pump, TPV 200V wastewater pump ... a TPV pump that also features dry-run protection in the form of a float switchAMIGA MH1100 4M pump ... a dry-mounted pressure pump for building services that reliably and quietly delivers clean water at a maximum of 5.2 bar?Jet centrifugal pump … a pump with a handle that, as a single-stage centrifugal pump, can be used in a variety of ways for garden irrigation. GAP X 80 Automatic Submersible Pressure Pump … an automatic submersible pressure pump designed for the reliable extraction of clear water from rain barrels, rainwater systems, flat tanks, and cisterns for the irrigation of gardens and green spaces.GAP X 120 Automatic Submersible Pressure Pump … a modern submersible pressure pump that operates underwater in a cistern or tank and features dry-run protection via an automatic switch integrated into the pump. GUP46 Clear Water Pressure Pump ... … a particularly durable pump for building services that operates as a submersible pressure pump underwater in the cistern or tank and is automatically controlled via a control unit (pressure switch, e.g., installed in the house). The pump operates via a side suction and is suitable for floating suction.

Feeder pump set

Includes control unit, ready to plug in Submersible pump to ensure operational reliability under exceptionally high geodetic conditions or pressure losses between the rainwater storage tank and the GRM 2.0 / GRM 3.0 rainwater manager, or under unfavorable suction conditions. Direct installation on the floating intake. Technical Data Weight in kg: 4.75 Max. head: 4.2 m Max. flow rate: 65 l/min

Floating suction filter for submersible pressure pumps

Compatible with GAP X120 & GUP 46 clear water pressure pumpsFor clear water pressure pumps with a 1-inch male thread1 m suction hose with 1-inch female thread connectionBrass check valveStainless steel suction filterWater intake in clean areas Sediment and suspended solids are not drawn in

GARDENA Comfort 4700/2 inox automatic - automatic rainwater barrel pump

Pressure-side pump connection set 1 inch

Reinforced hose with a 1-inch ball valve

Pump E.sybox - electron. pressure boosting system

DetailsThe E.sybox – your smart solution for boosting water pressure in the home. The E.sybox requires no additional components for installation. It consists of a self-priming multistage pump, an electronic inverter for speed control, flow and pressure sensors, a high-resolution rotatable LCD display, and an integrated 2-liter expansion tank. The E.sybox can be installed both vertically and horizontally. It can also be installed in tight, poorly ventilated spaces. The water-cooled motor, the ABS housing with sound-absorbing properties, the vibration-damping feet, and the electronics make it quiet (45 dB) and compact.

Pump E.sybox twin - electron. pressure boosting system

DetailsThe E.sybox – your smart solution for boosting water pressure in the home. The E.sybox requires no additional components for installation. It consists of a self-priming multistage pump, an electronic inverter for speed control, flow and pressure sensors, a high-resolution rotatable LCD display, and integrated 2-liter expansion tanks. The E.sybox can be installed both vertically and horizontally. It can also be installed in tight, poorly ventilated spaces. The water-cooled motor, the ABS housing with sound-absorbing properties, the vibration-damping feet, and the electronics make it quiet (45 dB) and compact.

Rain barrel pump GAP X80, automatic, with dry-running protection

GAP X80 Rainwater Tank Pump – Your Automatic Submersible Pump with Dry-Run Protection The GreenLife GAP X80 automatic submersible pump is a high-quality, reliable, and powerful device designed specifically for extracting clear water from rain barrels, rainwater systems, flat tanks, and cisterns. The pump can be used, among other things, for emptying rainwater storage tanks as well as for watering gardens and green spaces. The pump is fully submersible and is immersed in the water. Water delivery is automatically controlled when the line to the consumer is opened. When the consumer is closed, the pump switches to standby mode. The pump then enters start/stop mode and maintains pressure in the line. Included as an accessory is a telescopic tube with a bracket (hose kink protection) to position the pump at the edge of the tank. The convenient shut-off valve with quick-connect coupling allows you to easily draw water from the rainwater barrel. If the pump is located in a tank or cistern, a water connection box or garden tap can be operated directly via the ¾-inch connection. Product features and benefits at a glance Integrated dry-run protection & thermal fuse – protects the motor and pump from damage in case of low water level or overload Protection class IP X8 – for continuous operation underwater High flow rate – up to 83 l/min (5,000 l/h) at a maximum head of 20 meters (2.0 bar) Pumped medium: clear water – suitable for clean water, preferably filtered, max. temperature 35 °C Robust construction – fully submersible, housing made of durable plastic Fully ready for connection – includes a 10 m power cord, telescopic tube, shut-off valve, hose holder, quick-connect coupling, and mounting hardware Easy to handle – lightweight at 6.3 kg and with an integrated carrying handle Even easier for you: service & consultation included Expert advice on selection, installation, and combination with connection accessories Free shipping within Germany Guaranteed pickup service within Germany in case of repair during the 24-month statutory warranty period Applications Irrigation of gardens and green spaces – directly from rainwater storage tanks Operation of garden water taps and garden irrigation Can be integrated into automatic irrigation systems for balconies, patios, and home gardens Feed pump for flat tanks and cisterns in residential and commercial settings Notes Do not pump saltwater, wastewater, corrosive, highly flammable, or explosive substances (e.g., gasoline, kerosene, nitro thinner), or oils such as heating oil and vegetable oils! The water temperature must not exceed 35 °C. If there is a risk of frost, drain the pump and store it in a frost-proof location. Please follow the installation and operating instructions. Do you have questions? We’re here to help. Our customer service team is here to assist you with any questions regarding pump selection, installation, or accessories. Phone: 0385 / 77337-0 (7 a.m.–4 p.m.) Technical Support: 0385 / 77337-72 (8 a.m.–4 p.m.) Email: info@greenlife.de

Wall bracket for Amiga MH800 4M / MH1100 4M pumps

For the Amiga MH800 4M / MH1100 4M pumps made of stainless steel, including mounting hardware and rubber pads for noise and vibration damping

Wall bracket for automatic switch 54 / 65 / 87

For wall mounting of the 54 / 65 / 87 automatic switches Material: Stainless steel
